ASROCK X670E Taichi Amd X670 Socket

X670E Taichi

• Supports AMD Ryzen™ 7000 Series Processors
• 24+2+1 Phase Power Design, SPS for VCore+GT
• 4 x DDR5 DIMMs, supports up to 6600+(OC)
• 2 PCIe 5.0 x16
• Graphics Output Options: 2 USB4 Type-C, 1 HDMI
• Realtek ALC4082 5.1 CH HD Audio Codec,
• ESS SABRE9218 DAC, WIMA Audio Caps
• 1 Blazing M.2 (PCIe Gen5x4),
• 1 Hyper M.2 (PCIe Gen4x4 & SATA3),
• 2 Hyper M.2 (PCIe Gen4x4),
• 8 SATA3
• 2 USB4 Type-C (Rear),
• 1 USB 3.2 Gen2x2 Type-C (Front),
• 5 USB 3.2 Gen2 Type-A (Rear),
• 7 USB 3.2 Gen1 (3 Rear, 4 Front)
• Killer 2.5G LAN
• Killer 802.11ax Wi-Fi 6E + Bluetooth

• Superb Productivity
  • PCIe Gen5 (Graphics, M.2)
  • Blazing M.2 Gen5 Fan Heatsink
  • Dual Channel DDR5
  • USB4 TypeC Ports (40 Gb/s)
• RockSolid Durability
  • Ultra LowLoss PCB
  • 24+2+1 Power Phase, 105A SPS with Enlarged Heatsink Armor
  • Flexible Integrated I/O Shield
  • Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)
• Ultrafast Gaming
  • Killer 2.5G LAN, Killer 802.11ax WiFi 6E Module
  • Killer DoubleShot™ Pro
  • ASRock Lightning Gaming Ports
• EZ Update
  • BIOS Flashback Button
  • ASRock Auto Driver Installer

• Supports AMD Socket AM5 Ryzen™ 7000 Series Processors
• Supports ASRock Hyper BCLK Engine

• AMD X670

• Dual Channel DDR5 Memory Technology
• 4 x DDR5 DIMM Slots
• Supports nonECC, unbuffered memory up to 6600+(OC)
• Max. capacity of system memory: 128GB
• Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules

• 256Mb AMI UEFI Legal BIOS with GUI support

• Integrated AMD RDNA™ 2 graphics (Actual support may vary by CPU)
  • 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
  • 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 60Hz

• 5.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec)
• WIMA Audio Capacitors (For Front Outputs)
• ESS SABRE9218 DAC for Front Panel Audio (130dB SNR)
• Individual PCB Layers for R/L Audio Channel
• Impedance Sensing on Rear Out port
• Nahimic Audio

• 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
• Killer E3100G
• Supports Killer LAN Software
• Supports Killer DoubleShot™ Pro

• 802.11ax WiFi 6E Module
• Supports IEEE 802.11a/b/g/n/ac/ax
• Supports DualBand 2x2 160MHz with extended 6GHz band support
• 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
• Supports Bluetooth + High speed class II
• Supports MUMIMO
• Supports Killer LAN Software
• Supports Killer DoubleShot™ Pro

• CPU:
  • 2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/x8 modes
• Chipset:
  • 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
• Supports AMD CrossFire™
• 15μ Gold Contact in VGA PCIe Slot (PCIE1)

• CPU: 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode
• Chipset:
  • 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2230/2242/2260/2280/22110 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes
  • 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode
  • 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode
  • 4 x SATA3 6.0 Gb/s Connectors
• ASMedia ASM1061: 4 x SATA3 6.0 Gb/s Connectors

• 2 x USB4 TypeC (Rear)
• 1 x USB 3.2 Gen2x2 TypeC (Front)
• 5 x USB 3.2 Gen2 TypeA (Rear)
• 7 x USB 3.2 Gen1 (3 Rear, 4 Front)
• 4 x USB 2.0 (Front)

• 1 x Power LED and Speaker Header
• 1 x RGB LED Header
• 3 x Addressable LED Headers
• 1 x CPU Fan Connector (4pin)
• 1 x CPU/Water Pump Fan Connector (4pin) (Smart Fan Speed Control)
• 6 x Chassis/Water Pump Fan Connectors (4pin) (Smart Fan Speed Control)
• 1 x 24 pin ATX Power Connector (HiDensity Power Connector)
• 2 x 8 pin 12V Power Connectors (HiDensity Power Connector)
• 1 x Front Panel Audio Connector (15μ Gold Audio Connector)
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
• 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
• 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)
• 1 x Dr. Debug with LED
• 1 x Power Button with LED
• 1 x Reset Button with LED

• 2 x Antenna Ports
• 1 x HDMI Port
• 1 x Optical SPDIF Out Port
• 2 x USB4 TypeC Ports (40 Gb/s)
• 5 x USB 3.2 Gen2 TypeA Ports (10 Gb/s) (ReDriver) (USB32_12 are Lightning Gaming Ports. USB32_3 supports Ultra USB Power.)
• 3 x USB 3.2 Gen1 Ports
• 1 x RJ45 LAN Port
• 1 x Clear CMOS Button
• 1 x BIOS Flashback Button
• 1 x Line Out Jack (Gold Audio Jack)
• 1 x Microphone Input Jack (Gold Audio Jack)

• Software
  • ASRock Motherboard Utility (ATuning)
  • Killer Control Center
  • ASRock Polychrome SYNC
• UEFI
  • ASRock Full HD UEFI
  • ASRock Auto Driver Installer
  • ASRock Instant Flash

• 1 x User Manual
• 4 x SATA Data Cables
• 1 x Wireless Dongle USB Bracket
• 1 x Blazing M.2 Gen5 Fan Heatsink
• 1 x ASRock WiFi 2.4/5/6 GHz Antenna
• 4 x Screws for M.2 Sockets
• 1 x Standoff for M.2 Socket

• EATX Form Factor: 12.0in x 10.5in, 30.5 cm x 26.7 cm
• 8 Layer PCB

• Microsoft® Windows® 10 64bit / 11 64bit

• FCC, CE
• ErP/EuP ready (ErP/EuP ready power supply is required)
