ASROCK DESKMEET X300/B/BB/BOX/EU CPNT

DeskMini X300 Series

• AMD AM4 Socket CPU
  • Renoir, Picasso, Raven Ridge, up to 65W
  • Support MAX Height ≦ 46mm CPU Cooler
• Supports Overclocking Option with X300
• High-Speed DDR4-3200MHz Memory
• Dual Ultra M.2 (NVMe)
  • M2_1 M.2 (2280) – PCIe Gen3 x4
  • M2_2 M.2 (2280) – PCIe Gen3 x2/x4
• 2 x 2.5" SATA 6Gb Hard Drive
• Support RAID 0/1 function
• HDMI, DisplayPort, D-Sub
• M.2 For Wi-Fi Module
• USB 3.2 Gen1 Type-C

• Supports AMD AM4 Socket CPUs (Renoir, Picasso, Raven Ridge, up to 65W)

• Supports 2 x SO-DIMM DDR4 Memory, Max. 64GB
• AMD Ryzen 4000 series – 3200MHz
• AMD Ryzen 3000/2000 series – 2933MHz

• AMD X300

• HDMI(4K @60Hz)
• DisplayPort, D-Sub

• 1 x Head Phone with MIC Jack, 1 x MIC-In (RealtekALC233)

• 1 x USB 3.2 Gen1 Type-C, 1 x USB 3.2 Gen1 Type-A

• 1 x USB 3.2 Gen1 Type-A, 1 x USB 2.0 Type-A,

• 2 x SATA3 with Power connectors (RAID 0/1)
• 1 x Ultra M.2 (2280) PCIe Gen3 x4 SSD Slot
• 1 x Ultra M.2 (2280) Slot
  • PCIe Gen3 x4 (Renoir, Picasso and Raven Ridge APU)
  • PCIe Gen3 x2 (Athlon 2xxGE series APU)

• Gigabit LAN (RealtekRTL8111H)

• 1 x M.2 (key E 2230) Slot for Wi-Fi + BT Module

• 1 x USB 2.0 Header
• 1 x Front Panel Header
• 2 x 4-Pin fan connectors (CPU, SYS)
• 1 x DC-In Jack (Supports 19V Power Adapters)
• 1 x Internal Speaker Header (4-Pin)
• 1 x Chassis Intrusion Header (2-Pin)
• 1 x Audio Header (4-Pin)

• 2 x SATA Data with Power Cable
• 1 x 120W/19V adapter
• 1 x Screws Pack

• 155 x 155 x 80 mm (1.92L)

• DeskMini X300 Series don't support S3 function.
